System |
Main Processor | Industrial-grade processor |
Operating System | Embedded Linux |
Operating Interface | Web; Local GUI |
Perimeter Protection |
Perimeter Performance AI by Recorder (Number of Channels) | Advanced Model: 2 channels, 10 IVS for each channel
General Model: 8 channels, 10 IVS for each channel |
Face Detection |
Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
Face Detection Performance of AI by Recorder (Number of Channels) | 2 channels (up to 12 face images/s each channel) ) |
Face Recognition |
Face Database Capacity | Up to 10 face databases with 20,000 face images in total. Name, gender, birthday, address, certificate type, cerificate No., countries & regions and state can be added to each face image |
Face Recognition Performance of AI by Recorder (Number of Channels) | 2 channels |
SMD Plus |
SMD Plus by Recorder | 8 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change |
Audio and Video |
Analog Camera Input | 8 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect |
Camera Input | 1. CVI: 4K@25/30 fps; 6 MP@20 fps; 5 MP@25 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps; 720p@50/60 fps.
2. TVI: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps.
3. AHD: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps. |
IP Camera Input | Up to 16 channels of IPC access
8 IP channels by default + 8 channels (analog channels are converted to IP channels)
incoming bandwidth: 128 Mbps, recording bandwidth: 128 Mbps and outgoing bandwidth: 128 Mbps
*After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled. |
Encoding Capacity | Main stream:
4K@(1fps-7fps); 6 MP@(1fps-10fps); 5 MP@(1fps-12fps); 4K-N, 4 MP, 3 MP@(1fps-15fps); 4M-N, 1080p, 720p, 960H, D1,CIF@(1fps–25/30fps);
Sub stream: 960H@(1fps–15fps); D1/CIF@(1 fps–25/30fps) |
Dual-stream | Yes |
Video Bit Rate | 32 kbps–6144 kbps |
Audio Sampling | 8 kHz, 16 bit |
Audio Bit Rate | 64 kbps |
Video Output | 1 HDMI, 1 VGA
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable. |
Multi-screen Display | When IP extension mode not enabled: 1/4/8/9
When IP extension mode enabled: 1/4/8/9/16 |
Third-party Camera Access | ONVIF; Panasonic; Sony; Axis; Arecont; Samsung |
Compression Standard |
Video Compression | AI Coding; Smart H.265+; H.265; Smart H.264+; H.264 |
Audio Compression | G.711a; G.711u; PCM |
Network |
Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; P2P |
Mobile Phone Access | IOS; Android |
Interoperability | ONVIF 21.12; CGI |
Browser | Chrome, IE9 or later, Firefox |
Network Mode | Single-address mode |
Recording Playback |
Record Mode | General, motion detection; intelligent; alarm; POS |
Recording Playback | 1/4/9 |
Backup Method | USB device and network |
Playback Mode | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
Alarm |
General Alarm | Motion detection; video loss; tampering |
Anomaly Alarm | No disk; storage error; disk full; camera offline; IP conflict; MAC conflict |
Intelligent Alarm | Face detection; face recognition; perimeter protection |
Alarm Linkage | Record; snapshot (panoramic); IPC external alarm output; access controller; voice prompt; buzzer; log; preset; email |
Ports |
Audio Input | 1-channel RCA
8-channel BNC (Coaxial Audio) |
Audio Output | 1-channel RCA |
Two-way Talk | Yes (share the same audio input with the first channel) |
HDD Interface | 1 SATA port, up to 16TB capacity for each disk. The maximum HDD capacity varies with environment temperature. |
RS-485 | 1 port, for PTZ control |
USB | 2 (1 front USB 2.0 port, 1 rear USB 3.0 port) |
HDMI | 1 |
VGA | 1 |
Network Port | 1 (10/100/1000 Mbps Ethernet port, RJ-45) |
General |
Power Supply | DC 12V, 2A |
Power Consumption | <10 W (without HDD) |
Net Weight | 1.00 kg (2.21 lb) |
Gross Weight | 1.40 kg (3.09 lb) |
Product Dimensions | 260.0 mm × 237.9 mm × 47.6 mm (10.24'' × 9.37'' × 1.87'') (W × D × H) |
Packaging Dimensions | 333.0 mm × 89.0 mm × 315.0 mm (13.12'' × 3.51'' × 12.41'') (W × D × H) |
Operating Temperature | –10 °C to +55 °C (14 °F to +131 °F) |
Operating Humidity | 10%–90% (RH) |
Installation | Rack or desktop |
Certifications | CE: CE-LVD: EN 60950-1/IEC 60950-1
CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024
FCC: Part 15 Subpart B |
