System |
Main Processor | Industrial-grade processor |
Operating System | Embedded Linux |
Operating Interface | Web; Local GUI |
Perimeter Protection |
Perimeter Performance AI by Recorder (Number of Channels) | Advanced Model: 2 channels, 10 IVS for each channel
General Model: 4 channels, 10 IVS for each channel |
Face Detection |
Face Attributes | Gender; age group; glasses; expressions; face mask; beard |
Face Detection Performance of AI by Recorder (Number of Channels) | 2 channels (up to 8 face images/s each channel) ) |
Face Recognition |
Face Database Capacity | Up to 20 face databases with 20,000 face images in total. Name, gender, birthday, address, certificate type, certificate No., countries & regions and state can be added to each face image |
Face Recognition Performance of AI by Recorder (Number of Channels) | 2 channels |
SMD Plus |
SMD Plus by Recorder | 4 channels: Secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change |
Audio and Video |
Analog Camera Input | 4 BNC ports, supports HDCVI/AHD/TVI/CVBS auto-detect |
Camera Input | 1. CVI: 4K@25/30 fps; 6 MP@20 fps; 5 MP@20 fps; 5 MP@25 fps; 4 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps; 720p@50/60 fps. 2. TVI: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps. 3. AHD: 4K@15 fps; 5 MP@20 fps; 4 MP@25/30 fps; 3 MP@25/30 fps; 1080p@25/30 fps; 720p@25/30 fps |
IP Camera Input | Up to 8 channels of IPC access
4 IP channels by default + 4 channels (analog channels are converted to IP channels)
incoming bandwidth: 64 Mbps, recording bandwidth: 64 Mbps and outgoing bandwidth: 64 Mbps
*After IP channels are added beyond the existing channels, the AI Function (IVS, SMD, FACE) will be disabled |
Encoding Capacity | Main stream:
4K@(1 fps-7 fps); 6 MP@(1 fps-10 fps); 5 MP@(1 fps-12 fps); 4K-N, 4 MP, 3 MP@(1 fps-15 fps); 4M-N, 1080p, 720p, 960H, D1,CIF@(1 fps–25/30 fps);
Sub stream: 960H@(1 fps–15 fps); D1/CIF@(1 fps–25/30 fps) |
Dual-stream | Yes |
Video Bit Rate | 32 kbps–6144 kbps |
Audio Sampling | 8 kHz, 16 bit |
Audio Bit Rate | 64 kbps |
Video Output | 1 HDMI, 1 VGA
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable |
Multi-screen Display | When IP extension mode not enabled: 1/4
When IP extension mode enabled: 1/4/8/9 |
Third-party Camera Access | ONVIF; Panasonic; Sony; Axis; Arecont; Samsung |
Compression Standard |
Video Compression | AI Coding; Smart H.265+; H.265; Smart H.264+; H.264 |
Audio Compression | G.711a; G.711u; PCM |
Network |
Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; DDNS; Alarm Server; P2P; Auto Registration |
Mobile Phone Access | iOS; Android |
Interoperability | ONVIF 22.12(Profile T; Profile S; Profile G); CGI; SDK |
Browser | Chrome
IE9 or later
Firefox |
Network Mode | Single-address mode |
Recording Playback |
Record Mode | General, motion detection; intelligent; alarm; POS |
Recording Playback | 1/4 |
Backup Method | USB device and network |
Playback Mode | Instant playback, general playback, event playback, tag playback, smart playback (face and motion detection) |
Alarm |
General Alarm | Motion detection; video loss; video tampering |
Anomaly Alarm | No disk; disk error; disk full; offline; IP conflict; MAC conflict |
Intelligent Alarm | Face detection; face recognition; perimeter protection |
Alarm Linkage | Record; snapshot (panoramic); IPC external alarm output; voice prompt; buzzer; log; preset; email |
Ports |
Audio Input | 1-channel RCA
4-channel BNC (Coaxial Audio) |
Audio Output | 1-channel RCA |
Two-way Talk | Yes (share the same audio input with the first channel) |
HDD Interface | 1 SATA port, up to 16 TB capacity. The maximum HDD capacity varies with environment temperature. |
RS-485 | 1 port, for PTZ control |
USB | 2 (1 front USB 2.0 port, 1 rear USB 2.0 port) |
HDMI | 1 |
VGA | 1 |
Network Port | 1 (10/100 Mbps Ethernet port, RJ-45) |
General |
Power Supply | 12 VDC, 2 A |
Power Consumption | <7 W (without HDD) |
Net Weight | 1.16 kg (2.56 lb) |
Gross Weight | 1.75 kg (3.86 lb) |
Product Dimensions | 325.0 mm × 257.2 mm × 55.0 mm (12.80'' × 10.12'' × 2.17'') (W × D × H) |
Packaging Dimensions | 372.0 mm × 117.0 mm × 308.0 mm (14.65'' × 4.61'' × 12.13'') (W × D × H) |
Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
Operating Humidity | ≤93% (RH) |
Installation | Rack or desktop |
Certifications | CE: CE-LVD: IEC 62368-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024, EN 55035 FCC: Part 15 Subpart B |
